| Wheel base | 2335±10 mm |
| Breakout Load | 2500kg |
| Bucket Capacity | 1.2m3 |
| Operating weight | 10300kg |
Specification Parameter
| Totallength(bucket at ground): | 6450±80mm |
| Total width: | 2490±20mm |
| Bucket width: | 2500mm |
| Total height (cabin top): | 3120±10mm |
| Total height (digging boom top): | 3940±20mm |
| Wheel base: | 2335±10 mm |
| Wheel tread: | 2139±10 mm |
| Rated load: | 2500KG |
| Operating weight: | 10300kg |
| Rated bucket capacity: | 1.2 m³ |
| Max. Dumping height (41°dumping angle): | 3050±50 mm |
| Dumping distance: | 870±20 mm |
| Turning radius: | 5750±50mm |
| Rated digging bucket capacity: | 0.3m³ |
| Max. Digging depth: | 3820±20 mm |
| Max. Digging radius: | 5345±20mm |
| Max. Loading height: | 3740±20mm |
| Max. Digging force: | 5100kgf |
| Max.Digging heigh: | 5470±20mm |
| Lifting force at Max. Digging radius: | 1220kg |
| Engine model: | YC4A105Z-T20 |
Corporate vision
FUKE is a specialist construction equipment manufacturer that focuses on developing, manufacturing and supplying of material handling equipment and heavy equipment for the global market. Based on the professional expertise of our employees, we are large enough to handle large production of various construction equipment with solutions tailored to your specific needs. Our goal is to offer the products with the highest quality at the most affordable price to serve your changing needs. We continue to strive to earn your ongoing trust with our expert support, in-depth knowledge and innovation, getting the job done with results beyond your expectation.
