| Volume | 10m³ |
| Water tank volume | 450L |
| Wheelbase | 1900+2950+1350mm |
| Overall mass | 13000kg |
| Displacement | 7.684L |
| Rated power | 226Kw |
Specification Parameter
| Volume | 10 |
| Chassis | FUKE |
| Engine | Yuchai |
| Overall mass | 13000kg |
| Max. permissible total mass | 31000kg |
| Overall dimensions(LxWxH) | 9680×2520×3960mm |
| Wheelbase | 1900+2950+1350mm |
| Min.ground clearance | 260mm |
| Min.turning diameter | 22m |
| Fuel consumption per 100km | ≤35L/100km |
| Braking distance(V0=30km/h) | ≤10(full load);≤9(no load)m |
| Bore*stroke | 112x130mmxmm |
| Displacement | 7.684L |
| Rated power/rpm | 226/2500kW/rpm |
| Maximum torque | 1100/1500N-m/rpm |
| Emission standard | National VI |
| Feeding speed | ≥8m³/min |
| Discharge speed | ≥5m³/min |
| Discharge residual rate | <0.5% |
| Slump range | 50～210mm |
| Water tank volume | 450L |
| Working pressure | 0.35-0.38Mpa |
| Engine | J08E-YK |
| Cab | QiXing |
Specification Parameter
Related products
Corporate vision
FUKE is a specialist construction equipment manufacturer that focuses on developing, manufacturing and supplying of material handling equipment and heavy equipment for the global market. Based on the professional expertise of our employees, we are large enough to handle large production of various construction equipment with solutions tailored to your specific needs. Our goal is to offer the products with the highest quality at the most affordable price to serve your changing needs. We continue to strive to earn your ongoing trust with our expert support, in-depth knowledge and innovation, getting the job done with results beyond your expectation.
