| Concrete output | 1.6m3 |
| Max. Load | 3540kg |
| Max. Torque | 237Nm |
| Operating weight | 5000 kg |
| Max. capacity | 90L/min |
| Max. power | 55Kw |
Specification Parameter
| Engine Model | Yuchai | WATER SYSTEM | 24V"Self-priming" volumetric water pump withquick-suction |
| Total displacement | 2700cc -4 in line(no Cylinders) | ||
| Injection | Direct with mechanical control | ||
| Cooling | Water, dry air filter | Max capacity | 90 liters/min |
| Max power | 55Kw(75Hp) | One tank with a total capacity of | 260KG |
| Max torque | 237Nm@2000rpm | Geometrical drum volume | 2200 liters |
| Alternator | 28V--500Wa(18A) | Drum rotation speed | 15 rpm |
| Battery | 2x12V--60AH (272A) Road light system, rear working lights | Concrete produced as | 16m³ |
| Steering | Rear wheel steering | Max flow rate | 20/40 liters/min |
| Drive type | 4X4 FOUR-WHEEL DRIVE | Volumetric capacity | 270 liters |
| Speed | 3 forward gears 3 reverse gears | Number of loading times | around 5 |
| Low speed | 0-70 Km/h | CAB | Closed cab with heating system, Tilting front window, Anatomic seat with flexible suspension and height adjustment |
| High speed | 0-40 Km/h | ||
| Axles and wheels | Front wheel is steering with planetary reduction gears on the lsuzu Axle with flanged gearbox | ||
| Wheel Tires | 12-165-12PR | Fuel tank | 110 liters |
| Max Load | 3540kg, 450kPa | Total hydraulic system capacity | 110 liters |
| RIM | 975 | Engine oil | 16 liters |
| Brakes | lnternal wheel hub disc service andemergency brakes acting on the 4 wheels, activation with mini servo pump on independent dual circuit. Negative type parking brake, with internal wheel hub discs on the front axle | Operating weight | 5000 kg |
| Max gross weight | 8500 kg | ||
| Load-carrying capacity | 3500 kg | ||
| LengthxWidth×Height | 6450×2350×2550 mm |
Specification Parameter
