| Gross weight | 14500kg |
| Main traction force | 85KN |
| Rated power | 154KW |
| Max. roll angle | 90° |
| Blade length | 3658mm |
| Rated rotary speed | 2200rpm |
Specification Parameter
| Gross weight | 14500 Kg | |
| Engine model | Yuchai | |
| Rated power | 154/210 KW/HP | |
| Rated speed | 2200 R/MIN | |
| Main traction force | 85 kn | |
| Blade cutting force | 7100 Kg | |
| Dimensions (length X width X height) | 8850X2600X3330 mm | |
| Wheelbase Front and rear axle wheelbase | 6300 mm | |
| Wheelbase of middle and rear axle | 1554 mm | |
| Left and right track | 2250 mm | |
| Steering system Maximum steering angle of front wheels | 50° | |
| Maximum articulated steering angle | 25° | |
| Minimum turning radius | 7500 mm | |
| Blade length | 3658 mm | |
| Blade string height | 610 mm | |
| Maximum roll angle | 90° | |
| Rotation angle | 360° | |
| Variation range of shovel angle | 30~65° | |
| Maximum lifting height | 455 mm | |
| Maximum penetration depth | 495 mm | |
Specification Parameter
