| Gross weight | 16000kg |
| Main traction force | 90KN |
| Rated power | 154KW |
| Max. roll angle | 90° |
| Blade length | 3962mm |
| Rated rotary speed | 2200rpm |
Specification Parameter
| Gross weight | 16000 Kg |
| Engine model | Yuchai |
| Rated power | 154/210 KW/HP |
| Rated speed | 2200 R/MIN |
| Main traction force | 90 kn |
| Blade cutting force | 7700 Kg |
| Dimensions (length x width x height) | 9250x2600x3330 mm |
| wheelbase Front and rear axle wheelbase | 6340 mm |
| wheelbase of middle and rear axle | 1554 mm |
| Left and right track | 2250 mm |
| Steering system Maximum steering angle of front wheels | 45(°) |
| Maximum articulated steering angle | 20(°) |
| Minimum turning radius | 8100 mm |
| Blade length | 3962 mm |
| Blade string height | 610 mm |
| Maximum roll angle | 90(%) |
| Rotation angle | 360(°) |
| Variation range of shovel angle | 30~65(°) |
| Maximum lifting height | 455 mm |
| Maximum penetration depth | 495 mm |
Specification Parameter
