| Gross weight | 16500kg |
| Main traction force | 110KN |
| Rated power | 160KW |
| Max. torque | 908N.m |
| Blade length | 4270mm |
| Rated rotary speed | 2200rpm |
Specification Parameter
| Total weight | 16500kg |
| Max traction force | 110kN |
| Blade cutting force | 780Okg |
| Min turning radius | 8100mm |
| Steering angle | 45° |
| Frame articulation angle | 20° |
| Front tilting angle | 17° |
| Front wheel wing angle | 15° |
| Length*Width*Heigh | 9250*2600*3330mm |
| Blade length | 4270mm |
| Blade angle of rotation | 360° |
| Blade tilting angle | 90° |
| Max lift height of the blade from ground | 455mm |
| Max depth of the blade | 495mm |
| Blade angle range | 30°~65° |
| Max climbing ability | 25° |
| Engine Model | Yuchai |
| Rated power | 160KW |
| Rated speed | 2200r/min |
| Max torque | 908N.m/1500rpm |
Specification Parameter
